Using the Ada Wiki Engine

By stephane.carrez

The Ada Wiki Engine is a small Ada library that parses a Wiki text in several Wiki syntax such as MediaWiki, Creole, Markdown and renders the result either in HTML, text or into another Wiki format. The Ada Wiki Engine is used in two steps:

  1. The Wiki text is parsed according to its syntax to produce a Wiki Document instance.
  2. The Wiki document is then rendered by a renderer to produce the final HTML or text.

The Ada Wiki Engine does not manage any storage for the wiki content so that it only focuses on the parsing and rendering aspects.

Overview

The Ada Wiki engine is organized in several packages:

  • Several Wiki stream packages define the interface, types and operations for the Wiki engine to read the Wiki or HTML content and for the Wiki renderer to generate the HTML or text outputs.
  • The Wiki parser is responsible for parsing HTML or Wiki content according to a selected Wiki syntax. It builds the final Wiki document through filters and plugins.


  • The Wiki filters provides a simple filter framework that allows to plug specific filters when a Wiki document is parsed and processed. Filters are used for the table of content generation, for the HTML filtering, to collect words or links and so on.
  • The Wiki plugins defines the plugin interface that is used by the Wiki engine to provide pluggable extensions in the Wiki. Plugins are used for the Wiki template support, to hide some Wiki text content when it is rendered or to interact with other systems.
  • The Wiki documents and attributes are used for the representation of the Wiki document after the Wiki content is parsed.
  • The Wiki renderers are the last packages which are used for the rendering of the Wiki document to produce the final HTML or text.

Building Ada Wiki Engine

Download the ada-wiki-1.0.1.tar.gz or get the sources from GitHub:

git clone git@github.com:stcarrez/ada-wiki.git ada-wiki

If you are using Ada Utility Library then you can configure with:

./configure

Otherwise, you should configure with:

./configure --with-ada-util=no

Then, build the library:

make

Once complete, you can install it:

make install

To use the library in your Ada project, add the following line in your GNAT project file:

with "wiki";

Rendering example

The rendering example described in this article generates an HTML or text content from a Wiki source file. The example reads the file in one of the supported Wiki syntax and produces the HTML or text. You will find the source file on GitHub in render.adb. The example has the following usage:

Render a wiki text file into HTML (default) or text
Usage: render [-t] [-m] [-M] [-d] [-c] [-s style] {wiki-file}
  -t        Render to text only
  -m        Render a Markdown wiki content
  -M        Render a Mediawiki wiki content
  -d        Render a Dotclear wiki content
  -g        Render a Google wiki content
  -c        Render a Creole wiki content
  -s style  Use the CSS style file

Parsing a Wiki Text

To render a Wiki text you will first need to parse the Wiki text and produce a Wiki document instance. For this you will need to declare the Wiki document instance and the Wiki parser instance:

with Wiki.Documents;
with Wiki.Parsers;
...
   Doc      : Wiki.Documents.Document;
   Engine   : Wiki.Parsers.Parser;

The Ada Wiki Engine has a filter mechanism that is used while parsing the input and before building the target wiki document instance. Filters are chained together and a filter can do some work on the content it sees such as blocking some content (filtering), collecting some data and doing some transformation on the content. When you want to use a filter, you have to declare an instance of the corresponding filter type.

with Wiki.Filters.Html;
with Wiki.Filters.Autolink;
with Wiki.Filters.TOC;
...
   Filter   : aliased Wiki.Filters.Html.Html_Filter_Type;
   Autolink : aliased Wiki.Filters.Autolink.Autolink_Filter;
   TOC      : aliased Wiki.Filters.TOC.TOC_Filter;

We use the Autolink filter that detects links in the text and transforms them into real links. The TOC filter is used to collect header sections in the Wiki text and builds a table of content. The Html filter is used to filter HTML content that could be contained in a Wiki text. By default it ignores several HTML tags such as html, head, body, title, meta (these tags are silently discarded). Furthermore it has the ability to hide several elements such as style and script (the tag and its content is discarded).

You will then configure the Wiki engine to build the filter chain and then define the Wiki syntax that the parser must use:

Engine.Add_Filter (TOC'Unchecked_Access);
Engine.Add_Filter (Autolink'Unchecked_Access);
Engine.Add_Filter (Filter'Unchecked_Access);
Engine.Set_Syntax (Syntax);

The Wiki engine gets its input from an Input_Stream interface that only defines a Read procedure. The Ada Wiki Engine provides several implementations of that interface, one of them is based on the Ada Text_IO package. This is what we are going to use:

with Wiki.Streams.Text_IO;
...
   Input    : aliased Wiki.Streams.Text_IO.File_Input_Stream;

You will then open the input file. If the file contains UTF-8 characters, you may open it as follows:

Input.Open (File_Path, "WCEM=8");

where File_Path is a string that represents the file's path.

Once the Wiki engine is setup and the input file opened, you can parse the Wiki text and build the Wiki document:

Engine.Parse (Input'Unchecked_Access, Doc);

Rendering a Wiki Document

After parsing a Wiki text you get a Wiki.Documents.Document instance that you can use as many times as you want. To render the Wiki document, you will first choose a renderer according to the target format that you need. The Ada Wiki Engine provides three renderers:

  • A Text renderer that produces text outputs,
  • A HTML renderer that generates an HTML presentation for the document,
  • A Wiki renderer that generates various Wiki syntaxes.

The renderer needs an output stream instance. We are using the Text_IO implementation:

with Wiki.Stream.Html.Text_IO;
with Wiki.Render.Html;
...
   Output   : aliased Wiki.Streams.Html.Text_IO.Html_File_Output_Stream;
   Renderer : aliased Wiki.Render.Html.Html_Renderer;

You will then configure the renderer to tell it the output stream to use. You may enable or not the rendering of Table Of Content and you just use the Render procedure to render the document.

Renderer.Set_Output_Stream (Output'Unchecked_Access);
Renderer.Set_Render_TOC (True);
Renderer.Render (Doc);

By default the output stream is configured to write on the standard output. This means that when Render is called, the output will be written to the standard output. You can choose another output stream or open the output stream to a file according to your needs.

Conclusion

The Ada Wiki Engine can be used to parse HTML content, sanitize the result through the HTML filter and convert it to text or to some Wiki syntax (have a look at the import.adb example). The engine can be extended through filters or plugins thus providing some flexible architecture. The library does not impose any storage mechanism. The Ada Wiki Engine is the core engine used by AWA Blogs and AWA Wiki web applications. You may have a look at some online Wiki in the Atlas Wiki demonstrator.

To add a comment, you must be connected. Login to add a comment

Using Ada LZMA to compress and decompress LZMA files

By stephane.carrez

liblzma is a public domain general-purpose data compression library with a zlib-like API. liblzma is part of XZ Utils which includes a gzip-like command line tool named xz and some other tools. XZ Utils is developed and maintained by Lasse Collin. Major parts of liblzma are based on Igor Pavlov's public domain LZMA SDK. The Ada LZMA library provides an Ada05 thin binding for the liblzma library and it allows to use all the operations provided by the compression and decompression library.

Setup of Ada LZMA binding

First download the Ada LZMA binding at http://download.vacs.fr/ada-lzma/ada-lzma-1.0.0.tar.gz or at git@github.com:stcarrez/ada-lzma.git, configure, build and install the library with the next commands:

./configure
make
make install

After these steps, you are ready to use the binding and you can add the next line at begining of your GNAT project file:

with "lzma";

Import Declaration

To use the Ada LZMA packages, you will first import the following packages in your Ada source code:

with Lzma.Base;
with Lzma.Container;
with Lzma.Check;

LZMA Stream Declaration and Initialization

The liblzma library uses the lzma_stream type to hold and control the data for the lzma operations. The lzma_stream must be initialized at begining of the compression or decompression and must be kept until the compression or decompression is finished. To use it, you must declare the LZMA stream as follows:

Stream  : aliased Lzma.Base.lzma_stream := Lzma.Base.LZMA_STREAM_INIT;

Most of the liblzma function return a status value of by lzma_ret, you may declare a result variable like this:

Result : Lzma.Base.lzma_ret;

Initialization of the lzma_stream

After the lzma_stream is declared, you must configure it either for compression or for decompression.

Initialize for compression

To configure the lzma_stream for compression, you will use the lzma_easy_encode function. The Preset parameter controls the compression level. Higher values provide better compression but are slower and require more memory for the program.

Result := Lzma.Container.lzma_easy_encoder (Stream'Unchecked_Access, Lzam.Container.LZMA_PRESET_DEFAULT,
                                            Lzma.Check.LZMA_CHECK_CRC64);
if Result /= Lzma.Base.LZMA_OK then
  Ada.Text_IO.Put_Line ("Error initializing the encoder");
end if;
Initialize for decompression

For the decompression, you will use the lzma_stream_decoder:

Result := Lzma.Container.lzma_stream_decoder (Stream'Unchecked_Access,
                                              Long_Long_Integer'Last,
                                              Lzma.Container.LZMA_CONCATENATED);

Compress or decompress the data

The compression and decompression is done by the lzma_code function which is called several times until it returns LZMA_STREAM_END code. Setup the stream 'next_out', 'avail_out', 'next_in' and 'avail_in' and call the lzma_code operation with the action (Lzma.Base.LZMA_RUN or Lzma.Base.LZMA_FINISH):

Result := Lzma.Base.lzma_code (Stream'Unchecked_Access, Action);

Release the LZMA stream

Close the LZMA stream:

    Lzma.Base.lzma_end (Stream'Unchecked_Access);

Sources

To better understand and use the library, use the source Luke

compress_easy.adb

decompress.adb

Download

https://github.com/stcarrez/ada-lzma

http://download.vacs.fr/ada-lzma/ada-lzma-1.0.0.tar.gz

To add a comment, you must be connected. Login to add a comment

Review Web Application: Listing the reviews

By stephane.carrez

After the creation and setup of the AWA project and the UML model design we have seen how to create a review for the review web application. In this new tutorial, you will understand the details to list the reviews that have been created and published. This tutorial has three steps:

  • First the definition of the database query,
  • The implementation of the Ada review list bean,
  • The writing of the XHTML facelet presentation file.

Step 1: Database query to list the reviews

Let's start with the database query that we will use to retrieve the reviews.

Since we need to access the list of reviews from the XHTML files, we will map the SQL query result to a list of Ada Beans objects. For this, an XML query mapping is created to tell how to map the SQL query result into some Ada record. The XML query mapping is then processed by Dynamo to generate the Ada Beans implementation. The XML query mapping is also read by AWA to get the SQL query to execute.

A template of the XML query mapping can be added to a project by using the dynamo add-query command. The first parameter is the module name (reviews) and the second parameter the name of the query (list). The command will generate the file db/reviews-list.xml.

dynamo add-query reviews list

The generated XML query mapping is an example of a query. You can replaced it or update it according to your needs. The first part of the XML query mapping is a class declaration that describes the type to represent each row returned by our query. Within the class, a set of property definition describes the class attributes with their type and name.

<query-mapping package='Atlas.Reviews.Models'>
    <class name="Atlas.Reviews.Models.List_Info" bean="yes">
        <comment>The list of reviews.</comment>
        <property type='Identifier' name="id">
            <comment>the review identifier.</comment>
        </property>
        <property type='String' name="title">
            <comment>the review title.</comment>
        </property>
        ...
    </class>
</query-mapping>

Following the class declaration, the query declaration describes a query by giving it a name and describing the SQL statement to execute. By having the SQL statement separate and external to the application, we can update, fix and tune the SQL without rebuilding the application. The Dynamo code generator will use the query declaration to generate a query definition that can be referenced and used from the Ada code.

The SQL statement is defined within the sql XML entity. The optional sql-count XML entity is used to associate a count query that can be used for the pagination.

We want to display the review with the author's name and email address. The list will be sorted by date to show the newest reviews first. The SQL to execute is the following:

<query-mapping package='Atlas.Reviews.Models'>
   ...
    <query name='list'>
       <comment>Get the list of reviews</comment>
       <sql>
SELECT
      r.id,
      r.title,
      r.site,
      r.create_date,
      r.allow_comments,
      r.reviewer_id,
      a.name,
      e.email,
      r.text
FROM atlas_review AS r
INNER JOIN awa_user AS a ON r.reviewer_id = a.id
INNER JOIN awa_email AS e ON a.email_id = e.id
ORDER BY r.create_date DESC
    LIMIT :first, :last
       </sql>
       <sql-count>
    SELECT
      count(r.id)
    FROM atlas_review AS r
       </sql-count>
    </query>
</query-mapping>

The query has two named parameters represented by :first and :last. These parameters allow to paginate the list of reviews.

The complete source can be seen in the file: db/reviews-list.xml.

Once the XML query is written, the Ada code is generated by Dynamo by reading the UML model and all the XML query mapping defined for the application. Dynamo merges all the definitions into the target Ada packages and generates the Ada code in the src/model directory. You can use the generate make target:

make generate

or run the following command manually:

dynamo generate db uml/atlas.zargo

From the List_Info class definition, Dynamo generates the List_Info tagged record. The record contains all the data members described in the class XML entity description. The List_Info represents one row returned by the SQL query. The attributes of the List_Info can be accessed from the XHTML files by using UEL expression and the property name defined for each attribute.

To describe the list of rows, Dynamo generates the List_Info_Beans package which instantiates the Util.Beans.Basic.Lists generic package. This provides an Ada vector for the List_Info type and an Ada bean that gives access to the list.

package Atlas.Reviews.Models is
  ...
  type List_Info is new Util.Beans.Basic.Readonly_Bean with record
  ...
   package List_Info_Beans is
      new Util.Beans.Basic.Lists (Element_Type => List_Info);
   package List_Info_Vectors renames List_Info_Beans.Vectors;
   subtype List_Info_List_Bean is List_Info_Beans.List_Bean;
   subtype List_Info_Vector is List_Info_Vectors.Vector;
   Query_List : constant ADO.Queries.Query_Definition_Access;
   ...
end Atlas.Reviews.Models;

The generated code can be seen in src/model/atlas-reviews-models.ads.

Step 2: The review list bean

In order to access the list of reviews from the XHTML facelet file, we must create an Ada bean that provides the list of reviews. This Ada bean is modelized in the UML model and we define:

  • A set of attributes to manage the review list pagination (page, page_size, count)
  • An Ada bean action that can be called from the XHTML facelet file (load)

The Review_List_Bean tagged record will hold the list of reviews for us:

package Atlas.Reviews.Beans is
  ...
   type Review_List_Bean is new Atlas.Reviews.Models.Review_List_Bean with record
      Module       : Atlas.Reviews.Modules.Review_Module_Access := null;
      Reviews      : aliased Atlas.Reviews.Models.List_Info_List_Bean;
      Reviews_Bean : Atlas.Reviews.Models.List_Info_List_Bean_Access;
   end record;
   type Review_List_Bean_Access is access all Review_List_Bean'Class;
end Atlas.Reviews.Beans;

We must now implement the Load operation that was described in the UML model and we are going to use our list query. For this, we use the ADO.Queries.Context to setup the query to retrieve the list of reviews. A call to Set_Query indicates the query that will be used. Since that query needs two parameters (first and last), we use the Bind_Param operation to give the two values. The list of reviews is then retrieved easily by calling the Atlas.Reviews.Models.List operation that was generated by Dynamo.

package body Atlas.Reviews.Beans is
...
   overriding
   procedure Load (Into    : in out Review_List_Bean;
                   Outcome : in out Ada.Strings.Unbounded.Unbounded_String) is
      Session     : ADO.Sessions.Session := Into.Module.Get_Session;
      Query       : ADO.Queries.Context;
      Count_Query : ADO.Queries.Context;
      First       : constant Natural  := (Into.Page - 1) * Into.Page_Size;
      Last        : constant Positive := First + Into.Page_Size;
   begin
      Query.Set_Query (Atlas.Reviews.Models.Query_List);
      Count_Query.Set_Count_Query (Atlas.Reviews.Models.Query_List);
      Query.Bind_Param (Name => "first", Value => First);
      Query.Bind_Param (Name => "last", Value => Last);
      Atlas.Reviews.Models.List (Into.Reviews, Session, Query);
      Into.Count := ADO.Datasets.Get_Count (Session, Count_Query);
   end Load;
end Atlas.Reviews.Beans;

Review list bean creation

The AWA framework must be able to create an instance of the Review_List_Bean type. For this, we have to declare and implement a constructor function that allocates an instance of the Review_List_Bean type and setup some pre-defined values. When the instance is returned, the list of reviews is not loaded.

package body Atlas.Reviews.Beans is
   ...
   function Create_Review_List_Bean (Module : in Atlas.Reviews.Modules.Review_Module_Access)
                                     return Util.Beans.Basic.Readonly_Bean_Access is
      Object  : constant Review_List_Bean_Access := new Review_List_Bean;
   begin
      Object.Module       := Module;
      Object.Reviews_Bean := Object.Reviews'Access;
      Object.Page_Size    := 20;
      Object.Page         := 1;
      Object.Count        := 0;
      return Object.all'Access;
   end Create_Review_List_Bean;
end Atlas.Reviews.Beans;

The constructor function is then registered in the Atlas.Reviews.Modules package within the Initialize procedure. This registration allows to give a name for this constructor function and be able to specify it in the managed-bean bean declaration.

package body Atlas.Reviews.Modules is
   ...
   overriding
   procedure Initialize (Plugin : in out Review_Module;
                         App    : in AWA.Modules.Application_Access;
                         Props  : in ASF.Applications.Config) is
   begin
      ...
      Register.Register (Plugin => Plugin,
                         Name   => "Atlas.Reviews.Beans.Review_List_Bean",
                         Handler => Atlas.Reviews.Beans.Create_Review_List_Bean'Access);
   end Initialize;
end Atlas.Reviews.Modules;

Review list bean declaration

The managed-bean XML declaration associates a name to a constructor function that will be called when the name is needed. The scope of the Ada bean is set to request so that a new instance is created for each HTTP GET request.

  <managed-bean>
    <description>The list of reviews</description>
    <managed-bean-name>reviewList</managed-bean-name>
    <managed-bean-class>Atlas.Reviews.Beans.Review_List_Bean</managed-bean-class>
    <managed-bean-scope>request</managed-bean-scope>
  </managed-bean>

Step 3: Listing the reviews: the XHTML facelet presentation file

To load the reviews to be displayed we will use a JSF 2.2 view action. The review list page has a parameter page that indicates the page number to be displayed. The f:viewParam allows to retrieve that parameter and configure the reviewList Ada bean with it. Then, the f:viewAction defines the action that will be executed after the view parameters are extracted, validated and passed to the Ada bean. In our case, we will call the load operation on our reviewList Ada bean.

<f:metadata>
    <f:viewParam id='page' value='#{reviewList.page}' required="false"/>
    <f:viewAction action="#{reviewList.load}"/>
</f:metadata>

To summarize, the reviewList Ada bean is created, then configured for the pagination and filled with the current page content by running our SQL query.

The easy part is now to render the list of reviews. The XHTML file uses the <h:list> component to iterate over the list items and render each of them. At each iteration, the <h:list> component initializes the Ada bean review to refer to the current row in the review list. We can then access each attribute defined in the XML query mapping by using the property name of that attribute. For example review.title returns the title property.

<h:list var="review" value="#{reviewList.reviews}">
    <div class='review' id="p_#{review.id}">
        <div class='review-title'>
            <h2><a href="#{review.site}">#{review.title}</a></h2>
            <ul class='review-info'>
                <li><span>By #{review.reviewer_name}</span></li>
                <li>
                    <h:outputText styleClass='review-date' value="#{review.date}" converter="dateConverter"/>
                </li>
                <h:panelGroup rendered="#{review.reviewer_id == user.id}">
                    <li>
                        <a href="#{contextPath}/reviews/edit-review.html?id=#{review.id}">#{reviewMsg.review_edit_label}</a>
                    </li>
                    <li>
                        <a href="#"
                           onclick="return ASF.OpenDialog(this, 'deleteDialog', '#{contextPath}/reviews/forms/delete-review.html?id=#{review.id}');">
                           #{reviewMsg.review_delete_label}
                        </a>
                    </li>
                </h:panelGroup>
            </ul>
        </div>
        <awa:wiki styleClass='review-text post-text' value="#{review.text}" format="dotclear"/>
    </div>
</h:list>

Understanding the request flow

Let's see the whole request flow to better understand what happens.

To display the list of reviews, the user's browser makes an HTTP GET request to the page /reviews/list.html. This page maps to the XHTML file web/reviews/list.xhtml that we created in the previous tutorial.

The Ada Server Faces framework handles the request by first reading the XHTML file and building a tree of components that represent the view to render. Within that tree of component, the <f:metadata> component allows to make a pre-initialization of components and beans before the component tree is rendered.

For the pre-initialization, the reviewList Ada bean is created because it is referenced in an EL expression used by the <f:viewParam> component or by the <f:viewAction>. For this creation, the Create_Review_List_Bean constructor that we registered is called. The page attribute is set on the reviewList Ada bean if it was passed as a URL request parameter.

The load action is then called by Ada Server Faces and the current review list page is retrieved by executing the SQL query.

As soon as the load action terminates, the rendering of the component tree can be processed. The reviewList Ada bean contains the information to display and the <h:list> component iterates over the list and renders each row at a time.

C

Conclusion

After the previous tutorial we were able to create a review and populate our database with one or several reviews. We are now able to display the list of reviews to our users.

The next tutorial will focus on using the Votes module to bring some voting capabilities in the review web application. Meanwhile, you may browse and study the sources:

db/reviews-list.xml

atlas-reviews-beans.ads

atlas-reviews-beans.adb

review-list.xhtml

To add a comment, you must be connected. Login to add a comment

Review Web Application: Creating a review

By stephane.carrez

In previous tutorials we have seen how to create and setup the project, design the UML model to generate the Ada implementation and the database schema. In this tutorial we will see how to design the page to create a review, implement the operations to create and populate the database with the new review.

Adding the review creation form

We will start with the presentation layer by adding two pages in our web application. A first page will contain the list of reviews and the second page will contain a form to create or update a review.

AWA uses the Facelets technology to allow developers write and design the presentation layer of the web application. This technology is commonly used in J2EE applications. A page is represented by an XML file that contains HTML code, includes some stylesheets, Javascript files and makes the link between the presentation and the web application.

Adding pages

Dynamo provides at least two commands that help in adding presentation files. The add-page command adds a simple page that can be edited and filled with real content. We will use it for the creation of the page to display the list of reviews.

dynamo add-page reviews/list

The add-form command creates another template of page that includes an HTML form to let a user submit some data to the web application.

dynamo add-form reviews/edit-review

These two commands will create the following files and they can now be modified.

./web/reviews/list.xhtml
./web/reviews/edit-review.xhtml
./web/reviews/forms/edit-review-form.xhtml

The create review form

In Facelets, an HTML form is created by using the <h:form> component from the HTML JSF namespace. This component will generate the HTML form tag and it will also manage the form submission.

The ASF framework provides a set of widget components that facilitate the design of web application. The <w:inputText> component renders a title field with an HTML <label> and an HTML <input> text. We will use it to let the user enter the review title and the site URL being reviewed. The HTML <textarea> is provided by the JSF component <h:inputTextArea>. The review submit form is defined by the following XML extract:

<h:form xmlns:h="http://java.sun.com/jsf/html
  xmlns:w="http://code.google.com/p/ada-asf/widget">
  <h:inputHidden id='entity-id' value='#{review.id}' required='false'/>
  <w:inputText title='Title' value='#{review.title}'/>
  <w:inputText title='Site' value='#{review.site}'/>
  <h:inputTextArea rows='20' value='#{review.text}'/>
  <h:commandButton value='Save'
     action='#{review.save}'/>
</h:form>

Before closing the <h:form> component, we will put a <h:commandButton> that will render the form submit button.

How it works

Before going further, let's see how all this works. The principle below is exactly the same for a Java Server Faces application.

First, when the page is rendered the UEL expressions that it contains are evaluated. The #{review.title}, #{review.site} and #{review.text} are replaced by the content provided by the review object which is an Ada Bean provided by the Review_Bean tagged record.

When the page is submitted by the user, the input values submitted in the form are saved in the review bean, again by using the UEL expression. The <h:commandButton> action is then executed. This is also an UEL that indicates a method to invoke on the bean.

To sum up, the UEL makes the binding between the presentation layer in Facelets files and the Ada or Java beans.

The Ada Bean layer provides getter and setter to allow the UEL to retrieve and set values. For this, the Review_Bean tagged record implements two operations that are defined in the Bean interface:

overriding
function Get_Value (From : in Review_Bean;
                    Name : in String) return Util.Beans.Objects.Object;

overriding
procedure Set_Value (From : in out Review_Bean;
                    Name : in String;
                    Value : in Util.Beans.Objects.Object);

The Get_Value operation is called to retrieve one of the Ada Bean member attribute and the Set_Value operation is called during form submission to set the member attribute.


Then the form button is pressed, the HTML form is submitted and received by the server. The <h:form> component identifies the form submission and each input component will validate the input fields. When everything has been validated, the <h:commandButton> component invokes the Save procedure that is declared as follows in the Review_Bean tagged record:

overriding
procedure Save (Bean : in out Review_Bean;
                Outcome : in out Ada.Strings.Unbounded.Unbounded_String);

In the Ada Bean layer, we have to call the business logic to perform the save operation.

The business logic part is provided by the Ada module whose initial skeleton was generated by Dynamo. That layer is responsible for defining how the data is created, retrieved and modified. As far as we are concerned, this is rather simple since we only have to verify the permission and save the review object within some transaction. In other modules, several objects may be envolved and more complex rules may be defined for the integrity and validity of these objects.

The last part of the architecture is the data model layer that was in fact generated by Dynamo from the UML model. It is responsible for loading and saving Ada objects into the database.

The Review_Bean type declaration

When we designed our UML model, we have created the Review_Bean UML class and gave that class the Bean stereotype. We also declared two operations (save and delete) on that class. With this definition, Dynamo has generated in the Atlas.Reviews.Models package the Review_Bean abstract type. This type is abstract because we have to implement the Save and Delete operations. These are the two operations that can be called by an action such as used by the <h:commandButton> component.

The Atlas.Reviews.Models package is a generated package and it must not be modified. To implement our Ada Bean, we will add the Review_Bean type in our own package: the Atlas.Reviews.Beans package.

For this the Review_Bean type will inherit from the Atlas.Reviews.Models.Review_Bean type and it will implement the required operations. The type declaration looks like this:

package Atlas.Reviews.Beans is
...
type Review_Bean is new Atlas.Reviews.Models.Review_Bean with record
   Module : Atlas.Reviews.Modules.Review_Module_Access := null;
end record;
...

The Review_Bean implementation

The Save and Delete procedure must be implemented and since the whole business logic is managed by the module layer, we just have to call the associated module procedure as follows:

overriding
procedure Save (Bean : in out Review_Bean;
                Outcome : in out Ada.Strings.Unbounded.Unbounded_String);
begin
   Bean.Module.Save (Bean);
end Save;

overriding
procedure Delete (Bean : in out Review_Bean;
                Outcome : in out Ada.Strings.Unbounded.Unbounded_String);
begin
   Bean.Module.Delete (Bean);
end Delete;

The Review_Bean creation

The AWA framework must be able to create the review bean instance when a page is processed. For this, there are three steps that are necessary:

  • we must define a create function whose role is to allocate the Review_Bean instance and return it. At the same time, the function can setup some pre-defined values for the object. The Dynamo tool has generated for us an example of such function so that there is nothing to do.
function Create_Review_Bean (Module : in Atlas.Reviews.Modules.Review_Module_Access)
   return Util.Beans.Basic.Readonly_Bean_Access is
   Object : constant Review_Bean_Access := new Review_Bean;
begin
   Object.Module := Module;
   return Object.all'Access;
end Create_Review_Bean;
  • the creation function must be registered in the AWA framework under a name that identifies the create function. Again, an example of this registration has been generated by Dynamo and we are going to use it as is.
Register.Register (Plugin => Plugin,
                 Name   => "Atlas.Reviews.Beans.Reviews_Bean",
                 Handler => Atlas.Reviews.Beans.Create_Review_Bean'Access);
  • the last step is the configuration step. In the module XML configuration file, we must declare the Ada bean name and indicate what create function must be called to create it. We will use the managed-bean XML declaration that comes from Java Server Faces. We can declare as many Ada beans as we want each of them with a different name.
  <managed-bean>
    <description>An example of a bean (change description and bean name)</description>
    <managed-bean-name>review</managed-bean-name>
    <managed-bean-class>Atlas.Reviews.Beans.Reviews_Bean</managed-bean-class>
    <managed-bean-scope>request</managed-bean-scope>
  </managed-bean>

When the UEL expression #{review.title} is used, the AWA framework looks for the Ada bean represented by review and identified by the managed-bean-name entry. It then calls the create function defined by the managed-bean-class. The Ada bean object is then stored either in the request context, a session context or an application context. This is defined by the managed-bean-scope entry. The request scope means that the Ada bean object is created once for each request. Concurrent page accesses will use their own Ada bean object instance. The session scope means that the Ada bean object is shared between requests on the same session. The application scope means that the Ada bean object is global to the application, shared by every request and every user.

Adding the module operations

Now, we must add two operations on the business logic to save a review and delete a review. The Dynamo code generator provides the add-module-operation command that will help us in this task. Let's run it:

dynamo add-module-operation reviews review Save
dynamo add-module-operation reviews review Delete

The first parameter is the name of the module where the new operation is added. This is the name of the module that was created by using the add-module operation. In our case, this is the reviews module.

The second parameter is the name of the database entity or database table if you prefer.

The add-module-operation command modifies the Ada module specification and body to define and implement the following operation:

package Atlas.Reviews.Modules is
...
procedure Save (Model  : in Review_Module;
                Entity : in out Atlas.Reviews.Models.Review_Ref'Class);
...

The object to save in the Review table is passed as parameter to the Save operation. The procedure body that was generated is rather simple but functional: it just saves the object in the database within a transaction. In many cases it is ready to use but you may also need to modify the operation to either change the implementation or even add new parameters.

Saving our review

Before saving our review entity object, we want to associate it with the current user. We have to know who is the current user and for this we can use the AWA service context. The AWA service context is an object that is provided by the AWA.Services.Contexts package and that provides some useful contextual information for the business logic:

  • It indicates the optional user that is authenticated and is doing the call,
  • It gives access to the database connections that the business logic can use,
  • It allows to manage database transactions.

The current service context is retrieved by using the AWA.Services.Contexts.Current function and we can use the Get_User function to know the current user. The Save procedure implementation is the following:

package ASC renames AWA.Services.Contexts;
procedure Save (Model  : in Review_Module;
                  Entity : in out Atlas.Reviews.Models.Review_Ref'Class) is
   Ctx   : constant ASC.Service_Context_Access := ASC.Current;
   DB    : ADO.Sessions.Master_Session := AWA.Services.Contexts.Get_Master_Session (Ctx);
begin
   Ctx.Start;
   if not Entity.Is_Inserted then
      Entity.Set_Reviewer (Ctx.Get_User);
      Entity.Set_Create_Date (Ada.Calendar.Clock);
   end if;
   Entity.Save (DB);
   Ctx.Commit;
end Save;

Setting up the permissions

Because we want to bring some minimal security to the Review Web Application, we are going to setup some permissions that will be enforced by the business logic layer when a save or delete operation is done. The AWA framework uses the Ada Security to implement and enforce permissions. For this we need:

  • An Ada definition of the permission,
  • Adding a verification to enforce the permission in the new module operations,
  • A definition of the permission rules.
Generating the permission

Dynamo provides the add-permissions command to help us in the first task. It generates some Ada code that declares the permissions. It also provides a default configuration for the new permissions.

dynamo add-permissions reviews review

The first parameter is the name of our module where the new permissions are declared and the second parameter is the name of the database entity. The command will modify the Ada module specification and add the following lines:

package Atlas.Reviews.Modules is
...
package ACL_Create_Reviews is new Security.Permissions.Definition ("review-create");
package ACL_Delete_Reviews is new Security.Permissions.Definition ("review-delete");
package ACL_Update_Reviews is new Security.Permissions.Definition ("review-update");

Each of these package instantiation, declares a single permission identified by a name.

Enforcing security

Now that we have our permission, we can enforce the security in the Save and Delete operation. This is done by using the Check operation provided by the AWA.Permissions package.

To verify that the user has the permission to create a new review, we can use the following call:

AWA.Permissions.Check (Permission => ACL_Create_Reviews.Permission);

Now, if we have a review to modify, we will use the update permission and also give the review object to the Check operation so that it can verify if that particular review can be modified.

AWA.Permissions.Check (Permission => ACL_Update_Reviews.Permission,
                       Entity => Entity);
Configuring the permission

Until now we have created the permission and enforced it in the business logic. We have not defined the rules that tell what is really checked to verify the permission. The configuration part is defined in the XML file config/reviews.xml that was generated when the reviews module was created. The add-permissions command has modified the XML file to provide some default configuration. It has generated a XML permission for the review-create, review-update and review-delete permissions.

The review-create permission is defined as follows:

<auth-permission>
    <name>review-create</name>
</auth-permission>

This XML definition associate the Authenticated Permission controller to the review-create permission. With that controller the permission is granted if the security context has a principal (ie, a user is authenticated).

The review-update permission has another definition that we must change. Basically, we want that only the reviewer that created the review can update the review. For this we will use the entity permission controller provided by AWA. The XML definition is the following:

<entity-permission>
    <name>review-update</name>
    <entity-type>altas_review</entity-type>
    <sql>
       SELECT r.id FROM atlas_review AS r
       WHERE r.id = :entity_id AND r.reviewer_id = :user_id
    </sql>
</entity-permission>

When the permission is checked, the entity permission controller will use the SQL statement to verify the permission. The SQL statement has three parameters:

  1. user_id is the ID of the user associated with the security context. If there is no authentified user, the permission is refused.
  2. entity_id is the ID of the database entity as passed to the Check procedure and propagated to the permission controller.
  3. entity_type is a unique number that identifies the database entity type or database table if you prefer. It is created and setup automatically according to the entity type defined in the entity-type XML member. It is not used in our example.

The above SQL statement verifies that the review exists and was created by the current user.

To learn more about permission, you may look at the AWA permissions documentation.

A word about navigation rules

We have seen that when the review creation form is submitted the <h:commandButton> component has invoked the Save procedure of our Review_Bean object. The review object has been created and saved in the database and we kept the relation between the new review and the user.

We must now decide what should happen for the user to see the result. We could display a new form, update some page content or redirect to a new page. All this is defined by the navigation rules.

The navigation rules is the Java Server Faces mechanism that controls and defines what is the next page or view that must be displayed to a user.

In the definition below, the navigation rule defines that the user is redirected to the page /reviews/list.xhtml if the current page was /reviews/edit-review.xhtml and the operation returned success.

<navigation-rule>
  <from-view-id>/reviews/edit-review.xhtml</from-view-id>
    <navigation-case>
      <from-outcome>success</from-outcome>
      <to-view-id>/reviews/list.xhtml</to-view-id>
      <redirect/>
    </navigation-case>
</navigation-rule>

The Review Web Application video

To help you in creating the review page and see how the whole process looks like in reality, I've created the following short video that details the above tutorial steps.

Conclusion

We have created a review form for the web application and we made the link between the presentation layer and the Ada code through the use of Ada Beans.

We implemented the business logic and saw how the review object is saved in the database. We defined the security of the application by creating specific permissions and we enforced the security in the Save and Delete operations.

The next tutorial will describe how to display a list of reviews for our application.

To add a comment, you must be connected. Login to add a comment

Ada Web Application: Building the UML model

By stephane.carrez

In the Ada Web Application: Setting up the project we have seen how to create a new AWA project. In this second article, we will see how to design the UML model, generate the Ada code and create the database tables from our UML design.

Introduction

A Model driven engineering or MDE promotes the use of models to ease the development of software and systems. The Unified Modeling Language is used to modelize various parts of the software. UML is a graphical type modelling language and it has many diagrams but we are only going to use one of them: the Class Diagram.

The class diagram is probably the most powerful diagram to design, explain and share the data model of any application. It defines the most important data types used by an application with the relation they have with each other. In the class diagram, a class represents an abstraction that encapsulates data member attributes and operations. The class may have relations with others classes.

For the UML model, we are going to use ArgoUML that is a free modelization tool that works pretty well. For the ArgoUML setup, we will use two profiles:

  • The Dynamo profile that describes the base data types for our UML model. These types are necessary for the code generator to work correctly.
  • The AWA profile that describes the tables and modules provided by AWA. We will need it to get the user UML class definition.

These UML profiles are located in the /usr/share/dynamo/base/uml directory after Dynamo and AWA are installed. To configure ArgoUML, go in the Edit -> Settings menu and add the directory in the Default XMI directories list. Beware that you must restart ArgoUML to be able to use the new profiles.


Modelize the domain model in UML

The UML model must use a number of Dynamo artifacts for the code generation to work properly. The artifact describes some capabilities and behavior for the code generator to perform its work. Stereotype names are enclosed within << and >> markers. Dynamo uses the following stereotypes:

  • The DataModel stereotype must be applied on the package which contains the model to generate. This stereotype activates the code generation (other packages are not generated).
  • The Table stereotype must be applied to the class. It controls which database table and Ada type will be generated.
  • The PK stereotype must be defined in at most one attribute of the class. This indicates the primary key for the database table. The attribute type must be an integer or a string. This is a limitation of the Ada code generator.
  • The Version stereotype must be applied on the attribute that is used for the optimistic locking implementation of the database layer.


In our UML model, the Review table is assigned the Table stereotype so that an SQL table will be created as well as an Ada tagged type to represent our table. The id class attribute represents the primary key and thus has the PK stereotype. The version class attribute is the database column used by the optimistic locking implementation provided by ADO. This is why is has the Version stereotype. The title, site, create_date, text and allow_comments attributes represent the information we want to store in the database table. They are general purpose attributes and thus don't need any specific stereotype. For each attribute, the Dynamo code generator will generate a getter and a setter operation that can be used in the Ada code.

To tune the generation, several UML tagged values can be selected and added on the table or on a table attribute. By applying a stereotype to the class, several tagged values can be added. By selecting the Tagged Values tab in ArgoUML we can edit and setup new values. For the Review table, the dynamo.table.name tagged value defines the name of the SQL database table, in our case atlas_review.


The text attribute in the Review table is a string that can hold some pretty long text. To control the length of the SQL column, we can set the dynamo.sql.length tagged value and tell what is that length.


Once the UML model is designed, it is saved in the project directory uml. Dynamo will be able to read the ArgoUML file format (.zargo extension) so there is no need to export the UML in XMI.

The Review application UML model

The final UML model of our review application is fairly simple. We just added a table and a bean declaration. To benefit from the user management in AWA, we can use the AWA::Users::Models::User class that is defined in the AWA UML model. The reviewed-by association will create an attribute reviewer in our class. The code generator will generate a Get_Reviewer and Set_Reviewer operation in the Ada code. The SQL table will contain an additional column reviewer that will hold the primary key of the reviewer.


The Review_Bean class is an Ada Bean abstract class that will be generated by the code generator. The Bean stereotype activates the bean code generator and the generator will generate some code support that is necessary to turn the Review_Bean tagged record into an Ada Bean aware type. We will see in the next tutorial that we will only have to implement the save and delete operation that are described in this UML model.

Makefile setup

The Makefile.in that was generated by the Dynamo create-project command must be updated to setup a number of generation arguments for the UML to Ada code generator. Edit the Makefile.in to change:

DYNAMO_ARGS=--package Atlas.Reviews.Models db uml/atlas.zargo

The --package option tells Dynamo to generate only the model for the specified package. The db directory is the directory that will contain the SQL model files.

Once the Makefile.in is updated, the Makefile must be updated by using the following command:

./config.status

Or if you prefer, you may run again the configure script to re-configure the whole project.

We need the code

To run the generator, we can use the generate make target:

make generate

The Dynamo code generator reads the file uml/atlas.zargo and the UML model it contains and generates:

  • the Ada package Atlas.Reviews.Models which contains the definition of the Review table. The model files are created in the directory src/models which is separate from your Ada sources.
  • the SQL files to create the MySQL or SQLite database. Depending on the AWA modules which are used, the generated SQL files will contain additional tables that are used by the AWA modules. The SQL files are generated in the db/mysql and db/sqlite directories.

Let's create the database

Until now we designed our application UML model, we have our Ada code generated, but we need a database with the tables for our application. We can do this by using the create-database command in Dynamo. This command needs several arguments:

  1. The directory that contains the SQL model files. In our case, this is db.
  2. The information to connect to the database, the database name, the user and its password. This information is passed in the form of a database connection string.
  3. The name of the database administration account to connect to the server and create the new database.
  4. The optional password for the database administration account.

If the MySQL server is running on your host and the admin account does not have any password, you can use the following command:

dynamo create-database  db 'mysql://localhost/demo_atlas?user=demo&password=demo' root

The create-database creates the database (demo_atlas) with the tables that are necessary for the application. It also creates the demo user and give it the necessary MySQL grants to connect to the demo_atlas database.

The Review Web Application UML video

To help you in building the UML model and see who the whole process looks like in reality, I've created the following short video that details the above tutorial steps.

Conclusion

Thanks to ArgoUML and Dynamo, generating the Ada model and database tables becomes a simple and fun task. We have not written any line of code yet in this Review Web Application project, everything has been generated but we achieved a big progress:

  • The Review Web Application server is built and can be launched,
  • The database is initialized and contains our application data model schema.

The next tutorial will explain how to design the review form, implement the operations to create and populate the database with the new review.

To add a comment, you must be connected. Login to add a comment

Ada Web Application: Setting up the project

By stephane.carrez

Ada Web Application is a complete framework that allows to write web applications using the Ada language. Through a complete web application, the tutorial explains various aspects in setting up and building an application by using AWA. The tutorial is split in several articles and they are completed by short videos to show how easy the whole process is.

The tutorial assumes that you have already installed the following software on your computer:

The review web application

The review web application allows users to write reviews about a product, a software or a web site and share them to the Internet community. The community can read the review, participate by adding comments and voting for the reviewed product or software.


The AWA framework provides several modules that are ready to be used by our application. The login and user management is handled by the framework so this simplifies a lot the design of our application. We will see in the tutorial how we can leverage this to our review application.

Because users of our review web application have different roles, we will need permissions to make sure that only reviewers can modify a review. We will see how the AWA framework leverages the Ada Security library to enforce the permissions.

The AWA framework also integrates three other modules that we are going to use: the tags, the votes and the comments.

Since many building blocks are already provided by the Ada framework, we will be able to concentrate on our own review application module.

Project creation with Dynamo

The first step is to create the new project. Since creating a project from scratch is never easy we will use the Dynamo tool to build our initial review web application. Dynamo is a command line tool that provides several commands that help in several development tasks. For the project creation we will give:

  • the output directory,
  • the project name,
  • the license to be used for the project,
  • the project author's email address.

Choose the project name with care as it defines the name of the Ada root package that will be used by the project. For the license, you have the choice between GPL v2, GPL v3, MIT, BSD 3 clauses, Apache 2 or some proprietary license.

dynamo -o atlas create-project -l apache atlas Stephane.Carrez@gmail.com

(Of course, change the above email address by your own email address, this is an example!)

The Dynamo project creation will build the atlas directory and populate it with many files:

  • A set of configure, Makefile, GNAT project files to build the project,
  • A set of Ada files to build your Ada web application,
  • A set of presentation files for the web application.

Once the project is created, we must configure it to find the Ada compiler, libraries and so on. This is done by the following commands:

cd atlas
./configure

At this step, you may even build your new project and start it. The make command will build the Ada files and create the bin/atlas-server executable that represents the web application.

make
bin/atlas-server

Once the server is started, you may point your browser to the following location: http://localhost:8080/atlas/index.html

Creating the review module with Dynamo

With the Ada Web Application framework, a web application is composed of modules where each module brings a specific functionality to the application. AWA provides a module for user management, another for comments, tags, votes, and many others. The application can decide to use these modules or not. The AWA module helps in defining the architecture and designing your web application.

For the review web application we will create our own module dedicated for the review management. The module will be an Ada child package of our root project package. From the Ada point of view, the final module will be composed of the following packages:

  • A Modules package represents the business logic of the module. It is provides operations to access and manage the data owned by the module.
  • A Beans package holds the Ada beans that make the link between the presentation layer and business logic.
  • A Models package holds the data model to access the database content. This package is generated from UML and will be covered by a next tutorial.

To help in setting up a new AWA module, the Dynamo tool provides the add-module command. You just have to give the name of the module, which is the name of the Ada child package. Let's create our reviews module now:

dynamo add-module reviews

The command generates the new AWA module and modifies some existing files to register the new module in the application. You can build your web application at this stage even though the new module will not do anything yet for you.

Eclipse setup

Launch you Eclipse and create the new project by going to the File -> New -> Project menu. Choose the Ada Project and uncheck the Use default location checkbox so that you can browse your file system and select the atlas directory.

That's it. If everything went well, you should be able to see the projects files in the Eclipse project explorer.


The Review Web Application setup video

To help you in setting up and see how the whole process looks like in reality, I've created the following short video that details the above tutorial steps.

Conclusion

The whole process takes less than 3 minutes and gives you the basis to setup and build your new web application. The next tutorial will explain how to use the UML to design and generate the data model for our Review Web Application.

To add a comment, you must be connected. Login to add a comment

Reading a program symbol table with Ada BFD

By stephane.carrez

The GNU Binutils provides support for reading and writing program files in various formats such as ELF, COFF. This support is known as the BFD, the Binary File Descriptor library (or the Big F*cking Deal). This article illustrates how an Ada application can use the BFD library to have access to a program symbol table.

Declarations

The Ada BFD library provides a set of Ada bindings that give access to the BFD library. A binary file such as an object file, an executable or an archive is represented by the Bfd.Files.File_Type limited type. The symbol table is represented by the Bfd.Symbols.Symbol_Table limited type. These two types hold internal data used and managed by the BFD library.

with Bfd.Files;
with Bfd.Sections;
with Bfd.Symbols;
...
  File    : Bfd.Files.File_Type;
  Symbols : Bfd.Symbols.Symbol_Table;

Opening the BFD file

The Open procedure must be called to read the object or executable file whose path is given as argument. The File_Type parameter will be initialized to get access to the binary file information. The Check_Format function must then be called to let the BFD library gather the file format information and verify that it is an object file or an executable.

Bfd.Files.Open (File, Path, "");
if Bfd.Files.Check_Format (File, Bfd.Files.OBJECT) then
    ...
end if;

Loading the symbol table

The symbol table is loaded by using the Read_Symbols procedure.

   Bfd.Symbols.Read_Symbols (File, Symbols);

The resources used by the symbol table will be freed when the symbol table instance is finalized.

Looking for a symbol

Once the symbol table is loaded, we can use the Get_Symbol function to find a symbol knowing its name. If the symbol is not found, a Null_Symbol is returned.

Sym  : Bfd.Symbols.Symbol := Bfd.Symbols.Get_Symbol (Symbols, "_main");
...
if Sym /= Bfd.Symbols.Null_Symbol then
   --  Symbol found
end if;

Each symbol has the following set of information:

  • A name (it may not be unique),
  • A set of flags that describe the symbol (global, local, weak, constructor, TLS, ...),
  • A symbol value,
  • A section to which the symbol belongs.
Sec   : constant Bfd.Sections.Section := Bfd.Symbols.Get_Section (Sym);
Flags : constant Bfd.Symbol_Flags     := Bfd.Symbols.Get_Flags (Sym);
Value : constant Bfd.Symbol_Value    := Bfd.Symbols.Get_Value (Sym);

Before interpreting and using the symbol value returned by Get_Value, you must look at the section to check for an undefined symbol. Indeed, undefined symbols being not yet resolved by the linker they have no value and no section. You can check that by using the Is_Undefined_Section function:

if Bfd.Sections.Is_Undefined_Section (Sec) then
   Ada.Text_IO.Put_Line ("undefined symbol");
end if;

When the symbol is defined, you must look at the flags and also the section information to know more about it.

if (Flags and Bfd.Symbols.BSF_GLOBAL) /= 0 then
  Ada.Text_IO.Put_Line ("global symbol in section "
               & Bfd.Sections.Get_Name (Sec)
               & " := " & Bfd.Symbol_Value'Image (Value));

elsif (Flags and Bfd.Symbols.BSF_LOCAL) /= 0 then
  Ada.Text_IO.Put_Line ("local symbol in section "
               & Bfd.Sections.Get_Name (Sec)
               & " := " & Bfd.Symbol_Value'Image (Value));

else
  Ada.Text_IO.Put_Line ("other symbol in section "
                                     & Bfd.Sections.Get_Name (Sec)
                                     & " := " & Bfd.Symbol_Value'Image (Value));
end if;

Conclusion and references

Reading an executable symbol table has been made fairly simple with the use of the Ada BFD library. Furthermore, the library allows to scan the sections, read their content and even use the BFD disassembler.

symbol.adb

BFD Documentation

To add a comment, you must be connected. Login to add a comment

Using the Facebook API

By stephane.carrez

Through this article you will learn how to use the OAuth 2.0 framework to let an application access service provider APIs such as Facebook API, Google+ API and others. Althought this article uses Ada as programming language and Facebook as service provider, most part also applies to other programming languages and other service providers.

Overview

OAuth 2.0 is an open standard for authorization. It is used by service providers as authorization mechanism for most of their APIs. The authorization workflow is depicted below:

  • [1], first a user goes in the application which displays a link to the OAuth API provider asking the user to grant access to his data for the application,
  • [2], the user clicks on the authenticate link and grants access to the application,
  • [3.1], The OAuth server redirects the user to a callback URL and it provides an application grant code,
  • [3.3], The application ask the API provider to transform the grant code to an access token,
  • [4] The application invokes the API provider with the access token

OAuth Workflow

Registering the application

The first step is to register the application in the service provider (Facebook, Google+, Twitter, ...). This registration process is specific to the provider. From this registration, several elements will be defined:

  • An application id is allocated, This identifier is public. This is the client_id parameter in OAuth 2.0.
  • An application secret is defined. It must be kept private to the application. This is the secret parameter in OAuth 2.0.
  • A callback URL or domain name is registered in the service provider. As far as I'm concerned, I had to register the domain demo.vacs.fr.

Facebook OAuth

For the OAuth authorization process, we will use the Ada Security library and its Application type. We will extend that type to expose some EL variables and an EL method that will be used in the authorization process. The Ada Server Faces Application Example part 3: the action bean explains how to do that and many details will no be covered by this article.

type Facebook_Auth is new Security.OAuth.Clients.Application
     and Util.Beans.Basic.Readonly_Bean
     and Util.Beans.Methods.Method_Bean with private;

FB_Auth      : aliased Facebook.Facebook_Auth;

Before anything we have to initialize the Application type to setup the application identifier, the application secret, the provider URL and a callback URL.

FB_Auth.Set_Application_Identifier ("116337738505130");
FB_Auth.Set_Application_Secret ("xxxxxxxxxxx");
FB_Auth.Set_Application_Callback ("http://demo.vacs.fr/oauth/localhost:8080/demo/oauth_callback.html");

The first step in the OAuth process is to build the authorization page with the link that redirects the user to the service provider OAuth authorization process. The link must be created by using the Get_State and Get_Auth_Params functions provided by the Application type. The first one generates a secure unique key that will be returned back by the service provider. The second one builds a list of request parameters that are necessary for the service provider to identify the application and redirect the user back to the application once the authentication is done.

Id : constant String := "...";
State  : constant String := FB_Auth.Get_State (Id);
Params : constant String := FB_Auth.Get_Auth_Params (State, "read_stream");

For a Facebook authorization process, the URI would be created as follows:

URI : constant String := "https://www.facebook.com/dialog/oauth?" & Params;

For another service provider, the process is similar but the URL is different.

OAuth callback

When the user has granted access to his data, he will be redirected to the callback defined by the application. Most service providers will require that the OAuth callback be a public URL. If you want to run you application on localhost (which is the case when you are developing), you will need a second redirection. If you are using the Apache server, you can easily setup a rewrite rule:

RewriteRule ^/oauth/localhost:([0-9]+)/(.*) http://localhost:$1/$2 [L,R=302]

With the above rewrite rule, the callback given to the OAuth provider would look like:

http://demo.vacs.fr/oauth/localhost:8080/demo/oauth_callback.html

The OAuth provider will first redirect to the public internet site which will redirect again to localhost and port 8080.

Getting the OAuth access token

The next step is to receive the code parameter from the callback which grants the application access to the service provider API. For this, we will use an XHTML view file and a view action that will be executed when the page is displayed. When this happens, the EL method authenticate will be called on the facebook bean (ie, our FB_Auth instance).

<f:view xmlns:f="http://java.sun.com/jsf/core">
    <f:metadata>
        <f:viewAction action="#{facebook.authenticate}"/>
    </f:metadata>
</f:view>

The Authenticate procedure extracts from the request the OAuth state and code parameters. It verifies that the state parameter is a valid key that we submitted and it makes a HTTP POST request on the OAuth service provider to transform the code into an access token. This step is handled by the Ada Security library through the Request_Access_Token operation.

procedure Authenticate (From    : in out Facebook_Auth;
                        Outcome : in out Ada.Strings.Unbounded.Unbounded_String) is
   use type Security.OAuth.Clients.Access_Token_Access;

   F       : constant ASF.Contexts.Faces.Faces_Context_Access := ASF.Contexts.Faces.Current;
   State : constant String := F.Get_Parameter (Security.OAuth.State);
   Code  : constant String := F.Get_Parameter (Security.OAuth.Code);
   Session : ASF.Sessions.Session := F.Get_Session;
begin
   Log.Info ("Auth code {0} for state {1}", Code, State);
   if Session.Is_Valid then
      if From.Is_Valid_State (Session.Get_Id, State) then
         declare
            Acc : Security.OAuth.Clients.Access_Token_Access
              := From.Request_Access_Token (Code);
         begin
            if Acc /= null then
               Log.Info ("Access token is {0}", Acc.Get_Name);
               Session.Set_Attribute ("access_token",
                                      Util.Beans.Objects.To_Object (Acc.Get_Name));
            end if;
         end;
      end if;
   end if;
end Authenticate;

The access token must be saved in the user session or another per-user safe storage so that it can be retrieved later on. The access token can expire and if this happens a fresh new access token must be obtained.

Getting the Facebook friends

Until now we have dealt with the authorization process. Let's look at using the service provider API and see how the Ada Utility Library will help in this task.

Defining the Ada beans

To represent the API result, we will use an Ada bean object that can easily be used from a presentation page. For the Facebook friend, a name and an identifier are necessary:

type Friend_Info is new Util.Beans.Basic.Readonly_Bean with record
   Name : Util.Beans.Objects.Object;
   Id   : Util.Beans.Objects.Object;
end record;
type Friend_Info_Access is access all Friend_Info;

Having a bean type to represent each friend, we will get a list of friends by instantiating the Ada bean Lists package:

package Friend_List is new Util.Beans.Basic.Lists (Element_Type => Friend_Info);

Mapping JSON or XML to Ada

The Ada Utility library provides a mechanism that parses JSON or XML and map the result in Ada objects. To be able to read the Facebook friend definition, we have to define an enum and implement a Set_Member procedure. This procedure will be called by the JSON/XML parser when a given data field is recognized and extracted.

type Friend_Field_Type is (FIELD_NAME, FIELD_ID);

procedure Set_Member (Into : in out Friend_Info;
                      Field : in Friend_Field_Type;
                      Value : in Util.Beans.Objects.Object);

The Set_Member procedure is rather simple as it just populates the data record with the value.

procedure Set_Member (Into : in out Friend_Info;
                      Field : in Friend_Field_Type;
                      Value : in Util.Beans.Objects.Object) is
begin
   case Field is
      when FIELD_ID =>
         Into.Id := Value;

      when FIELD_NAME =>
         Into.Name := Value;

   end case;
end Set_Member;

The mapper is a package that defines and controls how to map the JSON/XML data fields into the Ada record by using the Set_Member operation. We just have to instantiate the package. The Record_Mapper generic package will map JSON/XML into the Ada record and the Vector_Mapper will map a list of JSON/XML elements following a given structure into an Ada vector.

package Friend_Mapper is
  new Util.Serialize.Mappers.Record_Mapper (Element_Type        => Friend_Info,
                                            Element_Type_Access => Friend_Info_Access,
                                            Fields              => Friend_Field_Type,
                                            Set_Member          => Set_Member);

package Friend_Vector_Mapper is
   new Util.Serialize.Mappers.Vector_Mapper (Vectors        => Friend_List.Vectors,
                                             Element_Mapper => Friend_Mapper);

Now we need to control how the JSON/XML fields are mapped to our Ada fields. For this we have to setup the mapping. The Facebook JSON structure is so simple that we can use the default mapping provided by the mapper. For this we use the Add_Default_Mapping procedure. We also have to tell what is the JSON mapping used by the friend vector mapper.

Friend_Map        : aliased Friend_Mapper.Mapper;
Friend_Vector_Map : aliased Friend_Vector_Mapper.Mapper;
...
   Friend_Map.Add_Default_Mapping;
   Friend_Vector_Map.Set_Mapping (Friend_Map'Access);

Creating the REST client

Now it would be nice if we could get an operation that invokes the service provider API through an HTTP GET operation and put the result in our Ada object. The Facebook friends API returns a list of friends which correspond to our Friend_List.Vectors. To get our operation, we just have to instantiate the Rest_Get_Vector operation with our vector mapper (the generic parameter is a package name).

procedure Get_Friends is
  new Util.Http.Rest.Rest_Get_Vector (Vector_Mapper => Friend_Vector_Mapper);

Calling the REST client

Invoking the service provider API is now as simple as calling a procedure. The URI must include the access token as parameter. The HTTP GET operation must be made using SSL/TLS since this is part of OAuth 2.0.

 List  : Friend_List.List_Bean;
...
   Get_Friends ("https://graph.facebook.com/me/friends?access_token="
                      & Token,
                      Friend_Vector_Map'Access,
                      "/data",
                      List.List'Access);

Now you are ready to use and access the user's data as easily as other information...

References

facebook.ads

facebook.adb

Facebook API

To add a comment, you must be connected. Login to add a comment

Process creation in Java and Ada

By stephane.carrez

When developping and integrating applications together it is often useful to launch an external program. By doing this, many integration and implementation details are simplified (this integration technic also avoids license issues for some open source software integration).

This article explains how to launch an external program in Java and Ada and be able to read the process output to get the result.

Java Process Creation

The process creation is managed by the ProcessBuilder Java class. An instance of this class holds the necessary information to create and launch a new process. This includes the command line and its arguments, the standard input and outputs, the environment variables and the working directory.

The process builder instance is created by specifying the command and its arguments. For this the constructor accepts a variable list of parameters of type String.

import java.lang.ProcessBuilder;
...
  final String cmd = "ls";
  final String arg1 = "-l";
  final ProcessBuilder pb = new ProcessBuilder(cmd, arg1);

When the process builder is initialized, we can invoke the start method to create a new process. Each process is then represented by an instance of the Process class. It is possible to invoke start serveral times and each call creates a new process. It is necessary to catch the IOException which can be raised if the process cannot be created.

import java.lang.Process;
...
  try {
    final Process p = pb.start();
    ...

  } catch (final IOException ex) {
    System.err.println("IO error: " + ex.getLocalizedMessage());
  }

The Process class gives access to the process output through an input stream represented by the InputStream class. With this input stream, we can read what the process writes on its output. We will use a BufferedReader class to read that output line by line.

import java.io.*;
...
  final InputStream is = p.getInputStream();
  final BufferedReader reader = new BufferedReader(new InputStreamReader(is));

By using the readLine method, we can read a new line after each call. Once the whole stream is read, we have to close it. Closing the BufferedReader will close the InputStream associated with it.

  String line;
  while ((line = reader.readLine()) != null) {
    System.out.println(line);
  }
  reader.close();

Last step is to wait for the process termination and get the exit status: we can use the waitFor method. Since this method can be interrupted, we have to catch the InterruptedException.

  try {
    ...
    final int exit = p.waitFor();
    if (exit != 0) {
      System.err.printf("Command exited with status %d\n", exit);
    }
  }  catch (final InterruptedException ex) {
    System.err.println("Launch was interrupted...");
  }

You can get the complete source from the file: Launch.java

Ada Process Creation

For the Ada example, we will create an application that invokes the nslookup utility to resolve a set of host names. The list of host names is provided to nslookup by writing on its standard input and the result is collected by reading the output.

We will use the Pipe_Stream to launch the process, write on its input and read its output at the same time. The process is launched by calling the Open procedure and specifying the pipe redirection modes: READ is for reading the process output, WRITE is for writing to its input and READ_WRITE is for both.

with Util.Processes;
with Util.Streams.Pipes;
...
   Pipe    : aliased Util.Streams.Pipes.Pipe_Stream;

   Pipe.Open ("nslookup", Util.Processes.READ_WRITE);

We can read or write on the pipe directly but using a Print_Stream to write the text and the Buffered_Stream to read the result simplifies the implementation. Both of them are connected to the pipe: the Print_Stream will use the pipe output stream and the Buffered_Stream will use the pipe input stream.

with Util.Streams.Buffered;
with Util.Streams.Texts;
...
   Buffer  : Util.Streams.Buffered.Buffered_Stream;
   Print   : Util.Streams.Texts.Print_Stream;
begin
      --  Write on the process input stream
   Buffer.Initialize (null, Pipe'Unchecked_Access, 1024);
   Print.Initialize (Pipe'Unchecked_Access);

Before reading the process output, we send the input data to be solved by the process. By closing the print stream, we also close the pipe output stream, thus closing the process standard input.

   Print.Write ("www.google.com" & ASCII.LF);
   Print.Write ("set type=NS" & ASCII.LF);
   Print.Write ("www.google.com" & ASCII.LF);
   Print.Write ("set type=MX" & ASCII.LF);
   Print.Write ("www.google.com" & ASCII.LF);
   Print.Close;

We can now read the program output by using the Read procedure and get the result in the Content string. The Close procedure is invoked on the pipe to close the pipe (input and output) and wait for the application termination.

   Content : Unbounded_String;

   --  Read the 'nslookup' output.
   Buffer.Read (Content);
   Pipe.Close;

Once the process has terminated, we can get the exit status by using the Get_Exit_Status function.

   Ada.Text_IO.Put_Line ("Exit status: "
       & Integer'Image (Pipe.Get_Exit_Status));


References

launch.adb

util-streams-pipes.ads

util-streams-buffered.ads

util-streams-texts.ads

To add a comment, you must be connected. Login to add a comment

Ada perfect hash generation with gperfhash

By stephane.carrez

A perfect hash function is a function that returns a distinct hash number for each keyword of a well defined set. gperf is famous and well known perfect hash generator used for C or C++ languages. Ada is not supported.

The gperfhash is a sample from the Ada Utility Library which generates an Ada package that implements such perfect hash operation. It is not as complete as gperf but allows to easily get a hash operation. The gperfhash tool uses the GNAT package GNAT.Perfect_Hash_Generators.

Pre requisite

Since the gperfhash tool is provided by the Ada Util samples, you must build these samples with the following command:

$ gnatmake -Psamples

Define a keyword file

First, create a file which contains one keyword on each line. For example, let's write a keywords.txt file which contains the following three keywords:

int
select
print

Generate the package

Run the gperfhash tool and give it the package name.

$ gperfhash -p Hashing keywords.txt

The package defines a Hash and an Is_Keyword function. The Hash function returns a hash number for each string passed as argument. The hash number will be different for each string that matches one of our keyword. You can give a string not in the keyword list, in that case the hash function will return a number that collides with a hash number of one or our keyword.

The Is_Keyword function allows to check whether a string is a keyword of the list. This is very useful when you just want to know whether a string is a reserved keyword in some application.

The package specification is the following:

--  Generated by gperfhash
package Hashing is

   function Hash (S : String) return Natural;

   --  Returns true if the string <b>S</b> is a keyword.
   function Is_Keyword (S : in String) return Boolean;

   type Name_Access is access constant String;
   type Keyword_Array is array (Natural range <>) of Name_Access;
   Keywords : constant Keyword_Array;
private
...
end Hashing;

How to use the hash

Using the perfect hash generator is simple:

with Hashing;

  if Hashing.Is_Keyword (S) then
     -- 'S' is one of our keyword
  else
     -- No, it's not a keyword
  end if;
To add a comment, you must be connected. Login to add a comment

Thread safe object pool to manage scarce resource in application servers

By stephane.carrez

Problem Description

In application servers some resources are expensive and they must be shared. This is the case for a database connection, a frame buffer used for image processing, a connection to a remote server, and so on. The problem is to make available these scarce resources in such a way that:

  • a resource is used by only one thread at a time,
  • we can control the maximum number of resources used at a time,
  • we have some flexibility to define such maximum when configuring the application server,
  • and of course the final solution is thread safe.

The common pattern used in such situation is to use a thread-safe pool of objects. Objects are picked from the pool when needed and restored back to the pool when they are no longer used.

Java thread safe object pool

Let's see how to implement our object pool in Java. We will use a generic class declaration into which we define a fixed array of objects. The pool array is allocated by the constructor and we will assume it will never change (hence the final keyword).

public class Pool<T> {
  private final T[] objects;

  public Pool<T>(int size) {
     objects = new T[size];
  }
  ...
}

First, we need a getInstance method that picks an object from the pool. The method must be thread safe and it is protected by the synchronized keyword. It there is no object, it has to wait until an object is available. For this, the method invokes wait to sleep until another thread releases an object. To keep track of the number of available objects, we will use an available counter that is decremented each time an object is used.

  private int available = 0;
  private int waiting = 0;
  public synchronized T getInstance() {
     while (available == 0) {
        waiting++;
        wait();
        waiting--;
     }
     available--;
     return objects[available];
  }

To know when to wakeup a thread, we keep track of the number of waiters in the waiting counter. A loop is also necessary to make sure we have an available object after being wakeup. Indeed, there is no guarantee that after being notified, we have an available object to return. The call to wait will release the lock on the pool and puts the thread is wait mode.

Releasing the object is provided by release. The object is put backed in the pool array and the available counter incremented. If some threads are waiting, one of them is awaken by calling notify.

  public synchronized void release(T obj) {
     objects[available] = obj;
     available++;
     if (waiting) {
        notify();
     }
  }

When the application is started, the pool is initialized and some pre-defined objects are inserted.

   class Item { ... };
...
   Pool<Item> pool = new Pool<Item>(10);
   for (int i = 0; i < 10; i++) {
       pool.release(new Item());
   }

Ada thread safe pool

The Ada object pool will be defined in a generic package and we will use a protected type. The protected type will guarantee the thread safe behavior of the implementation by making sure that only one thread executes the procedures.

generic
   type Element_Type is private;
package Util.Concurrent.Pools is
     type Element_Array_Access is private;
     Null_Element_Array : constant Element_Array_Access;
  ...
private
    type Element_Array is array (Positive range <>) of Element_Type;
    type Element_Array_Access is access all Element_Array;
     Null_Element_Array : constant Element_Array_Access := null;
end Util.Concurrent.Pools;

The Ada protected type is simple with three procedures, we get the Get_Instance and Release as in the Java implementation. The Set_Size will take care of allocating the pool array (a job done by the Java pool constructor).

protected type Pool is
  entry Get_Instance (Item : out Element_Type);
  procedure Release (Item : in Element_Type);
  procedure Set_Size (Capacity : in Positive);
private
  Available     : Natural := 0;
  Elements      : Element_Array_Access := Null_Element_Array;
end Pool;

First, the Get_Instance procedure is defined as an entry so that we can define a condition to enter in it. Indeed, we need at least one object in the pool. Since we keep track of the number of available objects, we will use it as the entry condition. Thanks to this entry condition, the Ada implementation is a lot easier.

protected body Pool is
  entry Get_Instance (Item : out Element_Type) when Available > 0 is
  begin
     Item := Elements (Available);
     Available := Available - 1;
  end Get_Instance;
...
end Pool;

The Release operation is also easier as there is no need to wakeup any thread: the Ada runtime will do that for us.

protected body Pool is
   procedure Release (Item : in Element_Type) is
   begin
      Available := Available + 1;
      Elements (Available) := Item;
   end Release;
end Pool;

The pool is instantiated:

type Connection is ...;
package Connection_Pool is new Util.Concurrent.Pools (Connection);

And a pool object can be declared and initialized with some default object:

P : Connection_Pool.Pool;
C : Connection;
...
   P.Set_Size (Capacity => 10);
   for I in 1 .. 10 loop
         ...
         P.Release (C);
   end loop;

References

util-concurrent-pools.ads

util-concurrent-pools.adb

To add a comment, you must be connected. Login to add a comment

Ada Server Faces Application Example part 3: the action bean

By stephane.carrez

In a previous article, I presented in the cylinder volume example the Ada Server Faces presentation layer and then the Ada beans that link the presentation and ASF components together. This article explains how to implement an action bean and have a procedure executed when a button is pressed.

Command buttons and method expression

We have seen in the presentation layer how to create a form and have a submit button. This submit button can be associated with an action that will be executed when the button is pressed. The EL expression is the mechanism by which we create a binding between the XHTML presentation page and the component implemented in Java or Ada. A method expression is a simple EL expression that represents a bean and a method to invoke on that bean. This method expression represent our action.

A typical use is on the h:commandButton component where we can specify an action to invoke when the button is pressed. This is written as:

<h:commandButton id='run' value='Compute'
       action="#{compute.run}"/>

The method expression #{compute.run} indicates to execute the method run of the bean identified by compute.

Method Bean Declaration

Java implements method expressions by using reflection. It is able to look at the methods implemented by an object and then invoke one of these method with some parameters. Since we cannot do this in Ada, some developer help is necessary.

For this an Ada bean that implements an action must implement the Method_Bean interface. If we take the Compute_Bean type defined in the Ada beans previous article, we just have to extend that interface and implement the Get_Method_Bindings function. This function will indicate the methods which are available for an EL expression and somehow how they can be called.

with Util.Beans.Methods;
...
   type Compute_Bean is new Util.Beans.Basic.Bean
          and Util.Beans.Methods.Method_Bean with record
      Height : My_Float := -1.0;
      Radius : My_Float := -1.0;
      Volume: My_Float := -1.0;
   end record;
   --  This bean provides some methods that can be used in a Method_Expression
   overriding
   function Get_Method_Bindings (From : in Compute_Bean)
      return Util.Beans.Methods.Method_Binding_Array_Access;

Our Ada type can now define a method that can be invoked through a method expression. The action bean always receives the bean object as an in out first parameter and it must return the action outcome as an Unbounded_String also as in out.

 procedure Run (From    : in out Compute_Bean;
                         Outcome : in out Unbounded_String);

Implement the action

The implementation of our action is quite simple. The Radius and Height parameters submitted in the form have been set on the bean before the action is called. We can use them to compute the cylinder volume.

procedure Run (From    : in out Compute_Bean;
                        Outcome : in out Unbounded_String) is
      V : My_Float;
   begin
      V := (From.Radius * From.Radius);
      V := V * From.Height;
      From.Volume := V * 3.141;
      Outcome := To_Unbounded_String ("compute");
   end Run;

Define the action binding

To be able to call the Run procedure from an EL method expression, we have to create a binding object. This binding object will hold the method name as well as a small procedure stub that will somehow tie the method expression to the procedure. This step is easily done by instantiating the ASF.Events.Actions.Action_Method.Bind package.

with ASF.Events.Actions;
...
   package Run_Binding is
     new ASF.Events.Actions.Action_Method.Bind
        (Bean  => Compute_Bean,
         Method => Run,
         Name    => "run");

Register and expose the action bindings

The last step is to implement the Get_Method_Bindings function. Basically it has to return an array of method bindings which indicate the methods provided by the Ada bean.

Binding_Array : aliased constant Util.Beans.Methods.Method_Binding_Array
  := (Run_Binding.Proxy'Unchecked_Access, Run_Binding.Proxy'Unchecked_Access);

overriding
function Get_Method_Bindings (From : in Compute_Bean)
   return Util.Beans.Methods.Method_Binding_Array_Access is
begin
   return Binding_Array'Unchecked_Access;
end Get_Method_Bindings;

What happens now?

When the user presses the Compute button, the brower will submit the form and the ASF framework will do the following:

  • It will check the validity of input parameters,
  • It will save the input parameters on the compute bean,
  • It will execute the method expression #{compute.run}:
    • It calls the Get_Method_Bindings function to get a list of valid method,
    • Having found the right binding, it calls the binding procedure
    • The binding procedure invokes the Run procedure on the object.

Next time...

We have seen the presentation layer, how to implement the Ada bean and this article explained how to implement an action that is called when a button is pressed. The next article will explain how to initialize and build the web application.

To add a comment, you must be connected. Login to add a comment

Ada Server Faces Application Example part 4: the server

By stephane.carrez 1 comments

In previous articles, we have seen that an Ada Server Faces application has a presentation layer composed of XHTML and CSS files. Similar to Java Server Faces, Ada Server Faces is a component-based model and we saw how to write the Ada beans used by the application. Later, we also learnt how an action bean can have a procedure executed when a button is pressed. Now, how can all these stuff fit together?

Well, to finish our cylinder volume example, we will see how to put everything together and get our running web application.

Application Initialization

An Ada Server Faces Application is represented by the Application type which holds all the information to process and dispatch requests. First, let's declare a variable that represents our application.

Note: for the purpose of this article, we will assume that every variable is declared at some package level scope. If those variables are declared in another scope, the Access attribute should be replaced by Unchecked_Access.

with ASF.Applications.Main;
...
   App : aliased ASF.Applications.Main.Application;

To initialize the application, we will also need some configuration properties and a factory object. The configuration properties are used to configure the various components used by ASF. The factory allows to customize some behavior of Ada Server Faces. For now, we will use the default factory.

with ASF.Applications;
...
   C        : ASF.Applications.Config;
   Factory : ASF.Applications.Main.Application_Factory;

The initialization requires to define some configuration properties. The VIEW_EXT property indicates the URI extension that are recognized by ASF to associate an XHTML file (the compute.html corresponds to the XHTML file compute.xhtml). The VIEW_DIR property defines the root directory where the XHTML files are stored.

C.Set (ASF.Applications.VIEW_EXT, ".html");
C.Set (ASF.Applications.VIEW_DIR, "samples/web");
C.Set ("web.dir", "samples/web");
App.Initialize (C, Factory);

Servlets

Ada Server Faces uses the Ada Servlet framework to receive and dispatch web requests. It provides a Faces_Servlet servlet which can be plugged in the servlet container. This servlet is the entry point for ASF to process incoming requests. We will also need a File_Servlet to process the static files. Note that these servlets are implemented using tagged records and you can easily override the entry points (Do_Get or Do_Post) to implement specific behaviors.

with ASF.Servlets.Faces;
with ASF.Servlets.Files;
...
   Faces : aliased ASF.Servlets.Faces.Faces_Servlet;
   Files   : aliased ASF.Servlets.Files.File_Servlet;

The servlet instances are registered in the application.

App.Add_Servlet (Name => "faces", Server => Faces'Access);
App.Add_Servlet (Name => "files", Server => Files'Access);

Once registered, we have to define a mapping that tells which URI path is mapped to the servlet.

App.Add_Mapping (Name => "faces", Pattern => "*.html");
App.Add_Mapping (Name => "files", Pattern => "*.css");

For the purpose of debugging, ASF provides a servlet filter that can be plugged in the request processing flow. The Dump_Filter will produce a dump of the request with the headers and parameters.

with ASF.Filters.Dump;
...
   Dump    : aliased ASF.Filters.Dump.Dump_Filter;

The filter instance is registered as follows:

App.Add_Filter (Name => "dump", Filter => Dump'Access);

And a mapping is defined to tell which URL will trigger the filter.

App.Add_Filter_Mapping (Name => "dump", Pattern => "*.html");

Application and Web Container

The application object that we created is similar to a Java Web Application packaged in a WAR file. It represents the application and it must be deployed in a Web Container. With Ada Server Faces this is almost the same, the application needs a Web container. By default, ASF provides a web container based on the excellent Ada Web Server implementation (other web containers could be provided in the future based on other web servers).

with ASF.Server.Web;
...
   WS : ASF.Server.Web.AWS_Container;

To register the application, we indicate the URI context path to which the application is associated. Several applications can be registered, each of them having a unique URI context path.

CONTEXT_PATH : constant String := "/volume";
...
WS.Register_Application (CONTEXT_PATH, App'Access);

Global Objects

An application can provide some global objects which will be available during the request processing through the EL expression. First, we will expose the application context path which allows to write links in the XHTML page that match the URI used for registering the application in the web container.

App.Set_Global ("contextPath", CONTEXT_PATH);

Below is an example of use of this contextPath variable:

<link media="screen" type="text/css" rel="stylesheet"
      href="#{contextPath}/themes/main.css"/>

Now, we will register the bean that we created for our application! This was explained in the Ada beans previous article.

with Volume;
...
   Bean    : aliased Volume.Compute_Bean;
...
   App.Set_Global ("compute", Util.Beans.Objects.To_Object (Bean'Access));

Note: For the purpose of this example, the Compute_Bean is registered as a global object. This means that it will be shared by every request. A future article will explain how to get a session or a request bean as in Java Server Faces.

Starting the server

Once the application is registered, we can start our server. Note that since Ada Web Server starts several threads that listen to requests, the Start procedure does not block and returns as soon as the server is started. The delay is necessary to let the server wait for requests during some time.

WS.Start;
delay 1000.0;

What happens to a request?

Let's say the server receives a HTTP GET request on /volume/compute.html. Here is what happens:

Volume ASF Flow

  • Ada Web Server receives the HTTP request
  • It identifies the application that matches /volume (our context path) and gives the control to it
  • The application identifies the servlet that processes the remaining URI, which is compute.html
  • It gives the control to the Dump_Filter filter and then to the Faces_Servlet servlet,
  • The faces servlet identifies the XHTML facelet file and reads the compute.xhtml file
  • ASF builds the component tree that describes the page and invokes the render response phase
  • While rendering, the EL expressions such as #{compute.radius} are evaluated and the value is obtained on our Bean global instance.
  • The HTML content is produced as part of the rendering process and returned by AWS.

References

asf_volume_server.adb

volume.ads

volume.adb

compute.xhtml

1 comments
To add a comment, you must be connected. Login to add a comment

Ada Server Faces Application Example part 2: the Ada beans

By stephane.carrez

The first article explained how to design the presentation page of an Ada Server Faces application. This article presents the Ada beans that are behind the presentation page.

Ada Bean and presentation layer

We have seen that the presentation page contains components that make references to Ada beans with an EL expression.

<h:inputText id='height' size='10' value='#{compute.height}'>
        <f:converter converterId="float" />
</h:inputText>

The #{compute.height} is an EL expression that refers to the height property of the Ada bean identified as compute.

Writing the Cylinder Ada Bean

The Ada bean is a instance of an Ada tagged record that must implement a getter and a setter operation. These operations are invoked through an EL expression. Basically the getter is called when the view is rendered and the setter is called when the form is submitted and validated. The Bean interface defines the two operations that must be implemented by the Ada type:

with Util.Beans.Basic;
with Util.Beans.Objects;
...
   type Compute_Bean is new Util.Beans.Basic.Bean with record
      Height : My_Float := -1.0;
      Radius : My_Float := -1.0;
   end record;

   --  Get the value identified by the name.
   overriding
   function Get_Value (From : Compute_Bean;
                       Name : String) return Util.Beans.Objects.Object;

   --  Set the value identified by the name.
   overriding
   procedure Set_Value (From  : in out Compute_Bean;
                        Name  : in String;
                        Value : in Util.Beans.Objects.Object);

The getter and setter will identify the property to get or set through a name. The value is represented by an Object type that can hold several data types (boolean, integer, floats, strings, dates, ...). The getter looks for the name and returns the corresponding value in an Object record. Several To_Object functions helps in creating the result value.

   function Get_Value (From : Compute_Bean;
                       Name : String) return Util.Beans.Objects.Object is
   begin
      if Name = "radius" and From.Radius >= 0.0 then
         return Util.Beans.Objects.To_Object (Float (From.Radius));

      elsif Name = "height" and From.Height >= 0.0 then
         return Util.Beans.Objects.To_Object (Float (From.Height));

      else
         return Util.Beans.Objects.Null_Object;
      end if;
   end Get_Value;

The setter is similar.

   procedure Set_Value (From  : in out Compute_Bean;
                        Name  : in String;
                        Value : in Util.Beans.Objects.Object) is
   begin
      if Name = "radius" then
         From.Radius := My_Float (Util.Beans.Objects.To_Float (Value));
      elsif Name = "height" then
         From.Height := My_Float (Util.Beans.Objects.To_Float (Value));
      end if;
   end Set_Value;

Register the Cylinder Ada Bean

The next step is to register the cylinder bean and associate it with the compute name. There are several ways to do that but for the purpose of this example, there will be a global instance of the bean. That instance must be aliased so that we can use the Access attributes.

 Bean  : aliased Compute_Bean;

The Ada bean is registered on the application object by using the Set_Global procedure. This creates a global binding between a name and an Object record. In our case, the object will hold a reference to the Ada bean.

App : aliased ASF.Applications.Main.Application;
...
   App.Set_Global ("compute", Util.Beans.Objects.To_Object (Bean'Unchecked_Access));

Next Time...

We have seen how the presentation layer and the Ada beans are associated. The next article will present the action binding that links the form submission action to an Ada bean method.

To add a comment, you must be connected. Login to add a comment

Ada Server Faces Application Example part 1: the presentation

By stephane.carrez 1 comments

Ada Server Faces is a framework which allows to write and build web applications. This article presents through a simple example how to use ASF to write a simple web application.

ASF Overview

Ada Server Faces uses a model which is very close to Java Server Faces. JSF and ASF use a component-based model for the design and implementation of a web application. Like traditional MVC models, the presentation layer is separated from the control and model parts. Unlike the MVC model, JSF and ASF are not request-based meaning there is not a specific controller associated with the request. Instead, each component that is part of the page (view) participate in the control and each component brings a piece of the model.

This first article will focus on the presentation layer through a simple example.

Cylinder Volume Example

The example computes the volume of a cylinder. A simple form with two input fields allows to enter the cylinder dimensions (the unit does not matter).

Volume form

ASF Templating

The presentation part is implemented by a facelet file and a CSS file. The facelet file is an XML file which contains XHTML elements as well as facelets and JSF/ASF components. The facelets and ASF components are specified in their own XML namespace. The ASF components form a tree of components (UIComponent) which is then used for displaying and processing form submissions.

At the root of the XML file is an f:view component which represents the root of the component tree. The typical page layout looks as follows. Note the #{contextPath} notation in the link reference. This is an EL expression that will be evaluated when the view is displayed (rendered in JSF terminology).

<f:view contentType="text/html"
        xmlns:ui="http://java.sun.com/jsf/facelets"
        xmlns:f="http://java.sun.com/jsf/core"
        xmlns:c="http://java.sun.com/jstl/core"
	xmlns:u="http://code.google.com/p/ada-asf/util"
        xmlns:h="http://java.sun.com/jsf/html">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
    <link media="screen" type="text/css" rel="stylesheet"
      href="#{contextPath}/themes/main.css"/>
    <title>Volume Cylinder</title>
</head>
<body>
  <div>
     <h1>Compute the volume of a cylinder</h1>
     ...
  </div>
</body>
</html>
</f:view>

The form, input fields and submit buttons have to be specified using a JSF/ASF component. The JSF/ASF component will make the link between the presentation (view) and the controller (beans). The h:form is the JSF/ASF component that represents our form. Note that there is no need to specify any form action attribute: the form action will be managed by JSF/ASF.

The input fields are identified by the h:input components. The input field is linked to the bean through the value EL expression. This expression specifies the bean name and attribute. When rendering the view, JSF/ASF will fetch the value from the named bean. On form submission, JSF/ASF will populate the bean with the submitted value.

The h:input component can contain a f:converter element which indicates a conversion operation to call when displaying or before populating the bean value.

<h:form id='compute'>
  <dl>
    <dt>Height</dt>
    <dd>
      <h:inputText id='height' size='10' value='#{compute.height}'>
        <f:converter converterId="float" />
      </h:inputText>
    </dd>
    <dt>Radius</dt>
    <dd>
        <h:inputText id='radius' size='10' value='#{compute.radius}'>
           <f:converter converterId="float"/>
        </h:inputText>
    </dd>
    <dt></dt>
    <dd>
        <h:commandButton id='run' value='Compute'
       action="#{compute.run}"/>
    </dd>
  </dl>
</h:form>

At the form end, the h:commandButton represents the submit button and the controller action to invoke on form submission. The method to invoke is defined with an EL method expression in the action attribute. Before invoking the method, JSF/ASF will verify the submitted values, convert them according to associated converters, populate the beans with the values.

Style

The page style is provided by a specific CSS file. The dl/dt/dd list is rendered as a table using the following CSS definitions. By changing the CSS file, a new presentation can be provided to users.

dl {
  float: left;
  width: 500px;
  border: 1px solid #bcd;
  background-color: #ffffff;
  padding: 10px;
  -moz-border-radius: 6px;
  -webkit-border-radius: 6px 6px;
}
dt {
  clear: left;
  float: left;
  font-weight: bold;
  width: 20%;
  height: 20px;
  line-height: 24px;
  padding: 5px;
}
dd {
  float: left;
  padding: 5px;
}

Next time...

In this article, I've shown how to write the presentation and style part of an Ada Server Faces application. The next article will present the Ada beans that are associated with this example.

1 comments
To add a comment, you must be connected. Login to add a comment

Ada Servlet Example

By stephane.carrez 1 comments

To write a web application, Java developers can use the servlet API. The servlet technology, created around 1997, is a simple and powerful framework on top of which many web applications and higher web frameworks have been created. This article shows how to write the same kind of web application in Ada.

Ada Servlet Framework

The Ada Servlet framework is provided by Ada Server Faces. It is an adaptation and implementation of the JSR 315 (Java Servlet Specification) for the Ada 05 language. The Ada API is very close to the Java API as it provides the Servlet, Filter, Request, Response and Session types with quite the same methods. It should be quite easy for someone who is familiar with Java servlets to write an Ada servlet.

The Ada Servlet implementation uses the Ada Web Server as a web server. In the future other other web servers such as Apache or Lighthttpd could be used.

Servlet Declaration

The servlet API is represented by the Servlet tagged type which represents the root of all servlets. A servlet must extend this Servlet tagged type and it can override one of the Do_Get, Do_Post, Do_Head Do_Delete, Do_Put, Do_Options or Do_Trace procedure. Each Do_XXX procedure receives a request object and a response object.

with ASF.Servlets;
with ASF.Requests;
with ASF.Responses;

package Volume_Servlet is
   use ASF;
   type Servlet is new Servlets.Servlet with null record;

   --  Called by the servlet container when a GET request is received.
   procedure Do_Get (Server   : in Servlet;
                     Request  : in out Requests.Request'Class;
                     Response : in out Responses.Response'Class);
end Volume_Servlet;

Servlet Implementation

The Do_Get procedure receives the request and response as parameter. Both objects are in out parameters because the servlet implementation can modify them. Indeed, the Java servlet API allows the servlet developer to set specific attributes on the request object (This allows to associate any kind of data to the request for later use when rendering the response).

Similar to the Java API, the response is written by using the Print_Stream object that is returned by the Get_Output_Stream function.

with ASF.Streams;
package body Volume_Servlet is
   procedure Do_Get (Server   : in Servlet;
                     Request  : in out Requests.Request'Class;
                     Response : in out Responses.Response'Class) is
      Output : Streams.Print_Stream := Response.Get_Output_Stream;
   begin
      Output.Write ("...");
      Response.Set_Status (Responses.SC_OK);
   end Do_Get;
end Volume_Servlet;

Note: the complete content is omitted for the clarity of this post.

Servlet Registration

With Java servlet 2.5 specification, servlets are registered exclusively through the web.xml application descriptor file. Since Java servlet 3.0, one can register servlets programmatically. With our Ada servlet, this is was we will do with the use of the Add_Servlet method.

Since the Ada runtime is not able to create dynamically an instance of any class (such as the Java newInstance method of the Java Class class), we have to create ourselves the servlet instance object and register it. The servlet instance is associated with a name.

Once registered, we have to define a mapping that tells which URL path is mapped to the servlet. This is done by the call to Add_Mapping: every URL that ends in .html will be handled by the servlet.

The Ada Server Faces framework provides a Web container in which the application must be registered (similar to the Java Web container). The registration is done by the Register_Application call which also specifies the URL prefix for the web application (Every URL starting with /volume will be served by this application).

with ASF.Server.Web;
with ASF.Servlets;
with Volume_Servlet;

procedure Volume_Server is
   Compute : aliased Volume_Servlet.Servlet;
   App     : aliased ASF.Servlets.Servlet_Registry;
   WS      : ASF.Server.Web.AWS_Container;
begin
   --  Register the servlets and filters
   App.Add_Servlet (Name => "compute",
                    Server => Compute'Unchecked_Access);

   --  Define servlet mappings
   App.Add_Mapping (Name => "compute",
                    Pattern => "*.html");

   WS.Register_Application ("/volume",
                            App'Unchecked_Access);

   WS.Start;

   delay 600.0;

end Volume_Server;

Compilation and Execution

The compilation of the Ada servlet example is done using a GNAT project file.

$ gnatmake -Psamples

It produces the volume_server which is our web server.

$ bin/volume_server

After the server is started, point your browser to http://localhost:8080/volume/index.html to look at the result.

References

volume_servlet.ads

volume_servlet.adb

volume_server.adb

HttpServlet

HttpServletResponse

HttpServletRequest

1 comments
To add a comment, you must be connected. Login to add a comment

Inserting a file in a JSF view with a custom component

By stephane.carrez 1 comments

Putting all this in a database is of course possible but it means that some administration interface is necessary when we change the blocks. Since the blocks are not intended to be changed too often, I prefered to have some simple solution and use plain text files for the storage.

The goal is now to make a JSF component that reads the file and insert it in the output page.

Step1: Write the UI Component class

The JSF component must inherit from UIComponentBase class. The class must implement the getFamily method to tell to what component family the component belongs.

 package example;
 public class UIFile extends UIComponentBase {
    public String getFamily() {
        return "UIFile";
    }
   ...
 }

The component only needs a file name as parameter. To make it simple, the file component is an attribute that cannot be bound to a value expression (ie, a #{xxx}). Define the file member and the accessor methods:

  public class UIFile extends UIComponentBase {
    protected String file;
    public String getFile() {
        return file;
    }
    public void setFile(String file) {
        this.file = file;
    }
  }

Now, the JSF component is ready and we need a renderer. To make it simple, you can make the component provide and implement the renderer. This is easier but you loose some flexibility. In our case, implementing the rendering in the JSF encodeBegin method is enough. To keep the example small, the file path must be absolute (in reality I'm using a servlet context parameter to configure the directory; this is left as an exercise :-)). To copy the file, I'm using the famous Apache IO library.

   import org.apache.commons.io.IOUtils;
   public class UIFile extends UIComponentBase {
    private static final char[] STOP = new char[0];
    public void encodeBegin(final FacesContext context)
      throws IOException {
        final String name = getFile();
        if (name == null || name.length() == 0) {
            return;
        }
        File f = new File(name);
        if (!f.exists()) {
            return;
        }
        final ResponseWriter rw = context.getResponseWriter();
        rw.writeText(STOP, 0, 0);
        FileInputStream is = null;
        try {
            is = new FileInputStream(f);
            final char[] data = IOUtils.toCharArray(is, "UTF-8");
            rw.write(data);
        } catch (IOException ex) {
        } finally {
            if (is != null) {
                try {
                    is.close();
                } catch (IOException ex) {
                }
            }
        }
   }
 }

For all this to work, there is a trick. The trick is that before writing the file content, we have to close any opened HTML element. This is done by calling writeText with an empty array. After that, the file data is written as is and unescaped.

Step2: Register the component in faces-config.xml

Once your UI component class is written, you have to register it in your faces-config.xml file:

    <component>
        <component-type>example.UIFile</component-type>
        <component-class>example.UIFile</component-class>
    </component>

Step3: Create the taglib

Then, write a taglib file. This is an XML file that tells Facelet the name of the tag in the XHTML file and how to bind that name to the new component.

 <facelet-taglib>
    <namespace>http://www.example.com/tool</namespace>
    <tag>
        <tag-name>insert</tag-name>
        <component>
            <component-type>example.UIFile</component-type>
        </component>
    </tag>
  </facelet-taglib>

Step4: Use the component

The last step is to use our new component in the XHTML file, this is as simple as this:

  <tool:insert file="myfile.html"/>
1 comments
To add a comment, you must be connected. Login to add a comment
  • Page 1
